MayTech brushless High Voltage ESC MT120A-HV-V2 (Harrier-Suprem Series) MT120A-HV-V2 manufacturer from China Maytech Electronics Co., Ltd

MayTech brushless High Voltage ESC MT120A-HV-V2 (Harrier-Suprem Series)

Payment Terms:	T/T
Place of Origin:	Shanghai, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: MT120A-HV-V2

Packing: individually packaging

Means of Transport: Land

Brand Name: Maytech

Continuous Current: 120Amps
Li-Po Cell Range: 6 to 12 Cells
Ni-xx Cell Range: 16 to 40 Cells
Max BEC Output: with NO internal BEC

Specifications:
Continuous Current: 120Amps
Li-Po Cell Range: 6 to 12 Cells
Ni-xx Cell Range: 16 to 40 Cells
Max BEC Output: with NO internal BEC

Size: 72 x 54 x 18 mm (2.8 x2.2 x 0.71 in)

Weight (Without Connectors): 110gm (3.9 oz)

To get the maximum throttle range, and smoothest throttle response, the MayTech Speed Controllers also have built-in Automatic Throttle Calibration. To activate this feature, power up the ESC with the transmitter on and in the full throttle position. After 2 seconds, the motor will beep two times. After the beeps are heard, reduce the throttle stick to the idle position and the motor will beep again indicating that the high and low throttle points are now calibrated. These values will be stored in the ESC and will remain in memory even after the ESC is shut down.
